What are the common symptoms of NTC EGT sensor failure?

Common symptoms of NTC EGT sensor failure
1. Abnormal resistance (short circuit/open circuit)
When an NTC thermistor shorts due to aging or poor welding, the resistance drops sharply. An open circuit results in infinite resistance, preventing the ECU from receiving a valid temperature signal.
2. High-temperature failure
Prolonged exposure to exhaust temperatures exceeding 900°C can cause internal components to melt or performance degradation, resulting in low readings or failure.
3. Mechanical vibration and wiring damage
Severe vibration or exhaust system modifications can loosen internal sensor connections, bend or break wiring, and cause intermittent alarms or signal interruptions.
4. Contamination and corrosion
Antifreeze, oil, or metal corrosion entering the sensor cavity can increase measurement errors and cause the exhaust temperature warning light to illuminate abnormally.
How can I quickly detect a malfunctioning EGT sensor?
1. On-site Voltage/Signal Testing
With the vehicle powered on, use a multimeter or diagnostic tool to measure the sensor's supply voltage and output voltage. The normal range should correspond to the technical manual; abnormal voltages directly indicate a sensor failure.
2. Offline Resistance Measurement
Unplug the sensor wiring harness and use a multimeter in the Ω range to measure resistance at different temperatures. The NTC characteristic should indicate a decrease in resistance with increasing temperature. If the resistance does not change with temperature or exceeds the specification, the sensor is considered faulty.
3. Oscilloscope Waveform Inspection
Observe the signal output waveform with an oscilloscope under idling or acceleration conditions. Normally, a sine wave with an amplitude >6V should be present. An absent waveform or excessive noise indicates damage to internal components or wiring.
4. Diagnostic Trouble Code Reading
Use an OBD diagnostic tool to read ECU fault codes and compare the real-time data stream with the temperature curve to quickly locate sensor anomalies or wiring problems.
